Product Description

533MMPro-01ASI533MM-Pro_02 ASI533MM-Pro_03 ASI533MM-Pro_04 ASI533MM-Pro_05 ASI533MM-Pro_06 ASI533MM-Pro_07 ASI533MM-Pro_08 ASI533MM-Pro_09 ASI533MM-Pro_10 ASI533MM-Pro_11ASI533MM-Pro_12  ASI533MM-Pro_133 ASI533MM-Pro_14

Camera technical details

  • Camera technical details
  • Sensor: Sony-IMX533CLK-D
  • Diagonal: 15.968mm
  • Resolution: 9 Mega Pixel 3008*3008
  • Pixel Size: 3.76μm
  • Max FPS at full resolution: 20fps
  • Shutter: Rolling shutter
  • Exposure Range: 32μs-2000s
  • ROI: Supported
  • Read Noise: 1.0-3.8e
  • QE peak: 91%
  • Full well: 50000e
  • ADC:14bit
  • Interface: USB 3.0 Type-B
  • Adaptor: M42X0.75
  • Protect window: D32-2-AR
  • Dimensions: 78mm Diameter
  • Weight: 470g
  • Back Focus Distance: 17.5mm
  • Delta T: 30°C-35°C below ambient
  • Camera Power consumption: 650mA at 5V
  • Cooler Power consumption: 12V at 3A Max
  • Working Temperature: -5°C—50°C
  • Storage Temperature: -10°C—60°C
  • Working Relative Humidity: 0%—80%
  • Storage Relative Humidity: 20%—95%
  • Max FPS at full resolution:
  • 14Bit ADC
  • 3008×3008 19.88fps
  • 1920×1080 54.11fps
  • 1280×720 79.74fps
  • 640×480 116.55ps
  • 320×240 216.45fps
    more resolutions are in software, support customize resolution.

Our website is continuously updated with the most recent camera drivers as well as software for DSO and planetary imaging. Please make sure the most recent Driver and software have been installed before you start shooting:

It is also recommended to read the Manuals first before shooting.
